Technical Specifications
| Model Name: | Vision Driver |
| Model Number: | VD-V1.2 |
| Operating Voltage and Current: | 110-260VAC, 2.5A |
| Weight: | 476 gr |
| Dimensions (Width x Length x Depth): | 317mm x 84mm x 51mm |
In the Vision Control Board, the power supply and the control card come together in a box. Thanks to its special algorithm, it provides ease of use to customers. By detecting the length, weight, and height of the door, it automatically adjusts the ramp areas, opening and closing speed.
- 2 Internal photocell sensors
- External photocell sensor input
- Internal and external motion sensor input
- Controlled battery charging circuit
- Fire Alarm Input
- Emergency Input
- Electromechanical lock and electromagnetic lock
- Airlock
- It automatically adjusts the opening and closing ramps.
- It automatically adjusts the opening and closing speed of the door according to the width, height, and weight of the door
- It provides safety with prevention scenario during opening and closing operation.
Areas of Usage:
- Full-Glass Automatic Sliding Door Systems
- Automatic Sliding Doors
- Telescopic Sliding Doors
